Comprehensive Guide to Commonly Used Electronic Components in IoT Industry

I. Introduction

With the rapid development of Internet of Things (IoT) technology, smart devices are permeating our daily lives and industrial applications at an unprecedented pace. As the core building blocks of IoT devices, electronic components directly impact product performance, power consumption, cost, and reliability. This article systematically introduces commonly used electronic components in the IoT industry and provides selection recommendations to help developers make informed decisions in complex market environments.

II. Microcontroller Unit (MCU) Recommendations

1. Low-Power MCUs

• ESP32 Series: Integrated Wi-Fi/Bluetooth dual-mode, excellent cost-performance ratio for smart home devices
• Nordic nRF52 Series: Ultra-low-power Bluetooth MCU, ideal for wearable devices
• STM32L Series: ST’s ultra-low-power product line with rich peripheral interfaces

2. High-Performance MCUs

• NXP i.MX RT Series: Crossover processors offering high performance with low power consumption
• Raspberry Pi RP2040: Dual-core ARM Cortex-M0+ with extensive ecosystem support

Selection Guidelines:

• Prioritize SoCs with integrated wireless functionality to minimize peripheral circuitry
• Balance performance and power requirements based on application scenarios
• Evaluate development toolchains and community support

III. Wireless Communication Modules

1. Short-Range Communication

• Wi-Fi Modules: ESP8266/ESP32 (Espressif), CY4343 (Cypress)
• Bluetooth Modules: nRF52840 (Nordic), CC2640 (TI)
• Zigbee Modules: CC2530 (TI), EFR32MG (Silicon Labs)

2. Long-Range Communication

• LoRa Modules: SX1276/SX1262 (Semtech), RA-02 (Ai-Thinker)
• NB-IoT Modules: BC95 (Quectel), ME3616 (Neoway)
• 4G Cat.1 Modules: EC600N (Quectel), A7600C1 (Fibocom)

Selection Guidelines:

• Consider network coverage, data rate, and power requirements
• Evaluate module certifications (e.g., FCC/CE)
• Pay attention to antenna design and RF matching circuits

IV. Sensor Selection Guide

1. Environmental Sensors

• Temperature/Humidity: SHT3x (Sensirion), DHT22 (low-cost option)
• Barometric Pressure: BMP280 (Bosch)
• Air Quality: CCS811 (AMS), PMS5003 (Plantower)

2. Motion Sensors

• Accelerometers: MPU6050 (TDK InvenSense), LSM6DSO (ST)
• Gyroscopes: BMG250 (Bosch)
• Magnetometers: HMC5883L (Honeywell)

3. Other Sensors

• Ambient Light: BH1750 (Rohm), TSL2561 (AMS-TAOS)
• Audio: INMP441 (Infineon) digital microphone
• Proximity/Gesture: APDS-9960 (Broadcom)

Selection Guidelines:

• Define measurement range, accuracy, and response time requirements
• Consider interface types (I2C/SPI/analog)
• Evaluate power consumption and wake-up characteristics

V. Power Management Components

1. Voltage Conversion

• LDOs: TPS7A series (TI), MCP1700 (Microchip)
• DC-DC Converters: TPS6274x (ultra-low-power), LM3671 (high-efficiency)

2. Battery Management

• Charging ICs: BQ25601 (TI), MCP73831 (Microchip)
• Fuel Gauges: MAX1704x (Maxim Integrated)

3. Energy Harvesting

• Solar: BQ25570 (TI)
• Vibration: LTC3588 (Analog Devices)

Selection Guidelines:

• Select topology based on input/output voltage and current requirements
• Prioritize light-load efficiency for extended battery life
• Consider power sequencing and dynamic voltage scaling needs

VI. Memory Device Selection

1. Volatile Memory

• SRAM: 23K256 (Microchip)
• PSRAM: APS6404L (AP Memory Technology)

2. Non-volatile Memory

• Flash: W25Q series (Winbond), AT25SF (Adesto)
• EEPROM: AT24C series (Microchip)
• FRAM: FM25V05 (Ramtron)

Selection Guidelines:

• Evaluate read/write speed, endurance, and data retention
• Consider interface compatibility (SPI/I2C/parallel)
• Prefer NOR Flash for firmware storage

VII. Peripheral Interface Components

1. Wired Communication

• USB: CP2102 (Silicon Labs) USB-to-UART
• CAN: MCP2562 (Microchip) CAN transceiver
• Ethernet: LAN8720 (Microchip) PHY chip

2. Human-Machine Interface

• Display Drivers: SSD1306 (OLED), ILI9341 (TFT)
• Touch: CAP1206 (Microchip)

3. Other Interfaces

• GPIO Expanders: PCA9536 (TI)
• ADC/DAC: ADS1115 (TI), MCP4725 (Microchip)

Selection Guidelines:

• Select appropriate bus expansion solutions based on system architecture
• Consider ESD protection and signal integrity
• Evaluate driver software and library support

VIII. Security Chip Recommendations

1. Encryption Chips

• ATECC608A (Microchip): Hardware encryption with ECC support
• SE050 (NXP): High-security element supporting multiple algorithms

2. Secure Elements

• OPTIGA™ (Infineon): TPM solutions
• STSAFE-A100 (ST): Secure authentication and key management

Selection Guidelines:

• Select appropriate security level based on requirements
• Consider cloud platform compatibility
• Evaluate certification standards (e.g., CC EAL)

IX. Comprehensive Selection Recommendations

1. System-Level Optimization: Select components from an architectural perspective, avoiding over-engineering
2. Supply Chain Considerations: Prioritize components with stable supply and multiple alternatives
3. Cost-Performance Balance: Find the optimal balance between performance and BOM cost
4. Manufacturability: Consider component packaging and soldering requirements
5. Long-Term Availability: Select components in early lifecycle stages

X. Future Trends

1. Higher Integration: SoCs integrating more functionality
2. Lower Power Consumption: Application of new materials and architectures
3. Edge AI: MCUs supporting machine learning inference
4. Emerging Memory Technologies: MRAM, ReRAM applications
5. Enhanced Security: Hardware-level security becoming standard

By carefully selecting and combining these electronic components, developers can build high-performance, reliable IoT devices that meet diverse application requirements. During actual component selection, we recommend creating evaluation boards for real-world testing to verify component performance meets expectations.
